Ce merveilleux article de Jonathan Caroll me donne une idée pour jouer avec le code ggplot2 et les palettes de couleurs scico :
Voir aussi ce toot de Stefan Siegert, inspirant !
J’ai pris le code du toot mentionné ci-dessus, je l’ai modifié et je l’ai utilisé pour m’amuser un peu en créant des graphiques qui ressemblent à des peintures avec des imperfections sur les bords, entre autres.
Dans l’ensemble, je pense que c’est un bon moyen de tester les palettes de couleurs.
Lorsque vous obtenez des images en points par pouce plus élevées, cela peut être vraiment cool.
#
library(tidyverse)
crossing(x=0:10, y=x) |>
mutate(dx = rnorm(n(), 0, (y/20)^1.5),
dy = rnorm(n(), 0, (y/20)^1.5)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour="black",
lwd=2, width=1, height=1, alpha=0.8, show.legend=FALSE) +
scale_fill_gradient(high="#9f025e", low='#f9c929') +
scale_y_reverse() + theme_void()
library(tidyverse)
crossing(x=8:300, y=x[1:100]) |>
mutate(dx = rnorm(n(), 0, (y/200)^1.5),
dy = rnorm(n(), 0, (y/100)^1.5)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour=NA,
lwd=4, width=8, height=4, alpha=0.1,
show.legend=FALSE) +
scale_fill_gradient(high="#9f025e", low='#f9c929') +
scale_y_reverse() + theme_void() +
coord_fixed()
Voici la palette de couleurs « Oléron » de chez scico. Quelle belle palette pour ceux qui connaissent cette île française !
library(tidyverse)
crossing(x=8:300, y=x[1:100]) |>
mutate(dx = rnorm(n(), 0, (y/200)^1.5),
dy = rnorm(n(), 0, (y/100)^1.5)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour=NA,
lwd=4, width=8, height=4, alpha=0.1,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "oleron",
direction = 1) +
scale_y_reverse() + theme_void() +
coord_fixed()
Dessinant maintenant les vagues, vue en haut de la dune :
crossing(x=8:300, y=x[1:100]) |>
mutate(dx = rnorm(n(), 0, (y/200)^1.5),
dy = ifelse(y < 52,
rnorm(n(), 0, (y/100)^1.5)+
ifelse(x %% 2 == 0,
cos(x * 3 + y / 5)*4 +
sin(x * 3 + y / 2)*2, 0) / 1.7,
rnorm(n(), 0, (y/100)^1.5))) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour=NA,
lwd=4, width=8, height=4, alpha=0.2,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "oleron", #begin = 0.6,
direction = 1) +
scale_y_reverse() + theme_void() +
coord_fixed()
Le vert pourrait être la végétation des dunes, ou peut-être des algues. Le bleu pourrait aussi être le ciel et le vent, l’heure bleue, il y a bien du sable.
Retour à des rectangles plus grands avec une palette scico cyclique : romaO.
crossing(x=1:280, y=x) |>
mutate(dx = rnorm(n(), 0, (x/40)^1.5),
dy = rnorm(n(), 0, (y/40)^1.5)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y-dy*3, fill=y), colour="white",
lwd=0.03, width=13, height=6, alpha=0.4,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "romaO", #begin = 0.6,
direction = 1) +
scale_y_reverse() + theme_void() +
theme(panel.background = element_rect(fill = "#2b2828")) +
coord_fixed()
Maintenant, jouez avec un peu plus de magie : coord_polar
crossing(x=1:280, y=x) |>
mutate(dx = rnorm(n(), 0, (x/40)^1.5),
dy = rnorm(n(), 0, (y/40)^1.5)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y-dy*3, fill=y), colour="white",
lwd=0.03, width=13, height=6, alpha=0.4,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "romaO", #begin = 0.6,
direction = 1) +
scale_y_reverse() + theme_void() +
theme(panel.background = element_rect(fill = "#2b2828")) +
coord_polar()
Un autre avec vikO palette:
crossing(x=8:70, y=x[1:30]) |>
mutate(dx = rnorm(n(), 0, (y/20)^1.5),
dy = rnorm(n(), 0, (y/10)^1.5)+ ifelse(x %%2 == 0, cos(x * 3 + y / 5)*10, 0)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour="grey70",
lwd=0.1, width=8, height=4, alpha=0.6,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "vikO", #begin = 0.6,
direction = -1) +
scale_y_reverse() +
theme_void() +
theme(panel.background = element_rect(fill = "#2b2828")) +
coord_polar(theta = "x")
Enfin revenons à la palette Oléron avec coord_polar :
crossing(x=8:70, y=x[1:30]) |>
mutate(dx = rnorm(n(), 0, (y/20)^1.5),
dy = rnorm(n(), 0, (y/10)^1.5)+ ifelse(x %%2 == 0, cos(x * 3 + y / 5)*10, 0)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour=NA,
lwd=1, width=8, height=4, alpha=0.4,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "oleron", #begin = 0.6,
direction = 1) +
scale_y_reverse() +
theme_void() +
theme(panel.background = element_rect(fill = "grey5")) + ##2b2828
coord_polar(theta = "x")
Un peu comme la Terre, mais pas depuis la Lune. Juste de R.
bukavu palette:
crossing(x=8:70, y=x[1:30]) |>
mutate(dx = rnorm(n(), 0, (y/20)^1.5),
dy = rnorm(n(), 0, (y/10)^1.5)+ ifelse(x %%2 == 0, cos(x * 3 + y / 5)*10, 0)) |>
ggplot() +
geom_tile(aes(x=x+dx, y=y+dy, fill=y), colour="grey5",
lwd=0.2, width=8, height=4, alpha=0.4,
show.legend=FALSE) +
scico::scale_fill_scico(palette = "bukavu", #begin = 0.6,
direction = 1) +
scale_y_reverse() +
theme_void() +
theme(panel.background = element_rect(fill = "#2b2828")) +
coord_polar(theta = "x")
Un grand merci à :
